At JMET, a globally renowned player in the steel market, we take immense pride in our specialization in rods and our unmatched track record in delivering exceptional products. Our expertise is evident in our Threaded Rod weight calculations, which are offered in various units such as millimeters, kilograms, and PDF formats. We understand the critical nature of accurate weight calculations and their impact on projects, and that’s why our calculations are meticulous, factoring in key parameters including diameter, threads per inch, width, and length. In this comprehensive guide, we will delve into the intricacies of our Threaded Rod weight calculations, providing valuable insights into our process and the advantages it offers.
The Science Behind JMET’s Threaded Rod Weight Calculations
The Significance of Precise Weight Calculations
Whether it’s construction, manufacturing, or any application involving rods, having an accurate understanding of threaded rod weights is paramount. Weight directly affects factors like load-bearing capacity, transport feasibility, and overall structural integrity. JMET recognizes the critical nature of these aspects and has crafted our Threaded Rod Weight Calculation approach to provide accuracy and reliability that project stakeholders can depend on.
Parameters Considered in our Calculations
Our comprehensive Threaded Rod weight calculations meticulously incorporate several crucial parameters that influence the weight of the rod:
- Diameter: The diameter of the rod plays a pivotal role in determining its weight. We consider this factor to ensure our weight calculations are tailored to the specific rod dimensions.
- Threads per Inch: The density of threads along the rod impacts its weight. Our calculations take into account the threads per inch, ensuring precision in the weight estimation.
- Width: The width of the rod is another contributing factor to its overall weight. Our calculations encompass this parameter for a comprehensive weight assessment.
- Length: Among the most influential factors, the length of the rod has a direct relationship with its weight. Our calculations incorporate length to provide an accurate weight approximation.
Advantages of JMET’s Approach
Precision and Dependability
JMET is committed to delivering precision and dependability across all our offerings, and our Threaded Rod weight calculations exemplify this commitment. Our systematic approach to factoring in multiple parameters guarantees that the weight measurements we provide align closely with the actual rod specifications.
Comprehensive Weight Charts for Ease of Use
To enhance the usability of our Threaded Rod weight calculations, we’ve developed meticulously curated weight charts that cater to diverse needs. Our Threaded Rod Weight Chart offers approximate kilogram per meter weights for a range of sizes, encompassing both metric (M) and UNC sizes. This chart serves as a quick reference, simplifying weight estimations.
Detailed Charts for Various Configurations
We recognize the variability of project requirements. To cater to these diverse needs, we provide an additional chart detailing kilogram per number values for varying lengths and diameters. This chart equips you with precise information for specific configurations.
Comprehensive DIN 975 Weight Data
For those seeking DIN 975 weight information, JMET has you covered. Our data comprises weights in kilograms per 1,000 pieces, spanning sizes from M2 to M48. These values are presented in ascending order based on sizes, ensuring straightforward access and reference.
Elevate Your Projects with JMET
In conclusion, JMET stands as your steadfast partner for all threaded rod requirements. Our Threaded Rod weight calculations, driven by a deep understanding of parameters and an unwavering commitment to precision, guarantee that your projects are executed with unwavering accuracy and confidence. Whether you’re engaged in construction, manufacturing, or any endeavor involving rods, our comprehensive weight calculations and informative charts are poised to elevate your project’s success.
For a visual representation of our Threaded Rod weight calculations, consider the following diagram:
Choose JMET as your partner today and experience the transformative impact that precision, expertise, and reliability can bring to your projects. Contact us to explore how our Threaded Rod weight calculations can propel your success to new horizons.
Fully Threaded Rods Weight Chart
| Approximate weight in Kgs per metre per pc. | |||
| Size (MM) | Weight per Metre | Size (UNC) | Weight per Mtr |
| M2 | 0.0187 | ||
| M2.5 | 0.030 | ||
| M3 | 0.044 | ||
| M3.5 | 0.060 | ||
| M4 | 0.078 | ||
| M5 | 0.124 | ||
| M6 | 0.177 | ¼” | 0.194 |
| M8 | 0.319 | 5/16” | 0.323 |
| M10 | 0.500 | 3/8” | 0.469 |
| 7/16” | 0.650 | ||
| M12 | 0.725 | ½” | 0.896 |
| M14 | 0.970 | 9/16” | 1.096 |
| M16 | 1.330 | 5/8” | 1.342 |
| M18 | 1.650 | ||
| M20 | 2.080 | ¾” | 2.021 |
| M22 | 2.540 | 7/8” | 2.756 |
| M24 | 3.000 | 1” | 3.638 |
| M27 | 3.850 | 1 1/8” | 4.545 |
| M30 | 4.750 | 1 ¼” | 5.718 |
| M33 | 5.900 | 1 3/8” | 6.842 |
| M36 | 6.900 | 1 ½” | 8.281 |
| M39 | 8.200 | 1 5/8” | 9.726 |
| M42 | 9.400 | 1 ¾” | 11.231 |
| M45 | 11.000 | 1 7/8” | 13.038 |
| M48 | 12.400 | 2 | 14.741 |
| APPROXIMATE WEIGHT IN KGS PER NO. | |||||||||||||
| LENGTH | D I A M E T E R | ||||||||||||
| 1/2″ | 5/8″ | 3/4″ | 7/8″ | 1″ | 1.1/8″ | 1.1/4″ | 1.3/8″ | 1.1/2″ | 1.5/8″ | 1.3/4″ | 1.7/8″ | 2″ | |
| 50 mm | 0.044 | 0.069 | 0.100 | 0.136 | 0.178 | 0.225 | 0.296 | 0.356 | 0.422 | 0.493 | 0.570 | 0.681 | 0.771 |
| 55 mm | 0.049 | 0.076 | 0.110 | 0.150 | 0.195 | 0.247 | 0.326 | 0.392 | 0.464 | 0.543 | 0.627 | 0.749 | 0.848 |
| 60 mm | 0.053 | 0.083 | 0.120 | 0.163 | 0.213 | 0.270 | 0.355 | 0.428 | 0.506 | 0.592 | 0.684 | 0.817 | 0.925 |
| 65 mm | 0.058 | 0.090 | 0.130 | 0.177 | 0.231 | 0.292 | 0.385 | 0.463 | 0.549 | 0.641 | 0.741 | 0.885 | 1.002 |
| 70 mm | 0.062 | 0.097 | 0.140 | 0.190 | 0.249 | 0.315 | 0.415 | 0.499 | 0.591 | 0.690 | 0.798 | 0.953 | 1.079 |
| 75 mm | 0.067 | 0.104 | 0.150 | 0.204 | 0.266 | 0.337 | 0.444 | 0.535 | 0.633 | 0.740 | 0.855 | 1.021 | 1.156 |
| 80 mm | 0.071 | 0.111 | 0.160 | 0.218 | 0.284 | 0.360 | 0.474 | 0.570 | 0.675 | 0.789 | 0.912 | 1.089 | 1.233 |
| 85 mm | 0.075 | 0.118 | 0.170 | 0.231 | 0.302 | 0.382 | 0.504 | 0.606 | 0.717 | 0.838 | 0.969 | 1.158 | 1.310 |
| 90 mm | 0.080 | 0.125 | 0.180 | 0.245 | 0.320 | 0.404 | 0.533 | 0.641 | 0.760 | 0.888 | 1.026 | 1.226 | 1.387 |
| 95 mm | 0.084 | 0.132 | 0.190 | 0.258 | 0.337 | 0.427 | 0.563 | 0.677 | 0.802 | 0.937 | 1.083 | 1.294 | 1.464 |
| 100 mm | 0.089 | 0.139 | 0.200 | 0.272 | 0.355 | 0.449 | 0.592 | 0.713 | 0.844 | 0.986 | 1.140 | 1.362 | 1.541 |
| 110 mm | 0.098 | 0.153 | 0.220 | 0.299 | 0.391 | 0.494 | 0.652 | 0.784 | 0.928 | 1.085 | 1.254 | 1.498 | 1.695 |
| 120 mm | 0.107 | 0.166 | 0.240 | 0.326 | 0.426 | 0.539 | 0.711 | 0.855 | 1.013 | 1.184 | 1.388 | 1.634 | 1.850 |
| 125 mm | 0.111 | 0.173 | 0.250 | 0.340 | 0.444 | 0.562 | 0.741 | 0.891 | 1.055 | 1.233 | 1.425 | 1.702 | 1.927 |
| 130 mm | 0.115 | 0.180 | 0.260 | 0.353 | 0.462 | 0.584 | 0.770 | 0.926 | 1.097 | 1.282 | 1.482 | 1.770 | 2.004 |
| 140 mm | 0.124 | 0.194 | 0.280 | 0.381 | 0.497 | 0.628 | 0.829 | 0.998 | 1.182 | 1.381 | 1.596 | 1.907 | 2.158 |
| 150 mm | 0.133 | 0.208 | 0.300 | 0.408 | 0.533 | 0.674 | 0.889 | 1.069 | 1.266 | 1.480 | 1.710 | 2.043 | 2.312 |
| 160 mm | 0.142 | 0.222 | 0.320 | 0.435 | 0.568 | 0.719 | 0.948 | 1.140 | 1.350 | 1.578 | 1.824 | 2.179 | 2.466 |
| 170 mm | 0.151 | 0.236 | 0.340 | 0.462 | 0.604 | 0.764 | 1.007 | 1.212 | 1.435 | 1.677 | 1.938 | 2.315 | 2.620 |
| 175 mm | 0.155 | 0.243 | 0.350 | 0.476 | 0.621 | 0.786 | 1.037 | 1.247 | 1.477 | 1.726 | 1.995 | 2.383 | 2.697 |
| 180 mm | 0.160 | 0.250 | 0.360 | 0.489 | 0.639 | 0.809 | 1.066 | 1.283 | 1.519 | 1.776 | 2.052 | 2.451 | 2.774 |
| 190 mm | 0.169 | 0.264 | 0.380 | 0.517 | 0.675 | 0.854 | 1.126 | 1.354 | 1.604 | 1.874 | 2.166 | 2.588 | 2.928 |
| 200 mm | 0.178 | 0.277 | 0.399 | 0.544 | 0.710 | 0.899 | 1.185 | 1.425 | 1.688 | 1.973 | 2.280 | 2.724 | 3.083 |
| 210 mm | 0.186 | 0.291 | 0.419 | 0.571 | 0.746 | 0.944 | 1.244 | 1.497 | 1.772 | 2.071 | 2.394 | 2.860 | 3.237 |
| 220 mm | 0.195 | 0.305 | 0.439 | 0.596 | 0.781 | 0.989 | 1.303 | 1.568 | 1.857 | 2.170 | 2.508 | 2.996 | 3.391 |
| 225 mm | 0.200 | 0.312 | 0.449 | 0.612 | 0.799 | 1.011 | 1.333 | 1.604 | 1.899 | 2.219 | 2.565 | 3.064 | 3.468 |
| 230 mm | 0.204 | 0.319 | 0.459 | 0.625 | 0.817 | 1.034 | 1.363 | 1.639 | 1.941 | 2.269 | 2.622 | 3.132 | 3.545 |
| 240 mm | 0.213 | 0.333 | 0.479 | 0.653 | 0.852 | 1.079 | 1.422 | 1.710 | 2.026 | 2.367 | 2.736 | 3.268 | 3.699 |
| 250 mm | 0.222 | 0.347 | 0.499 | 0.680 | 0.888 | 1.124 | 1.481 | 1.782 | 2.110 | 2.466 | 2.850 | 3.405 | 3.853 |
| 260 mm | 0.231 | 0.361 | 0.519 | 0.707 | 0.923 | 1.169 | 1.540 | 1.853 | 2.194 | 2.565 | 2.964 | 3.541 | 4.007 |
| 270 mm | 0.240 | 0.375 | 0.539 | 0.734 | 0.959 | 1.213 | 1.600 | 1.924 | 2.279 | 2.663 | 3.078 | 3.677 | 4.161 |
| 275 mm | 0.244 | 0.382 | 0.549 | 0.748 | 0.977 | 1.236 | 1.629 | 1.960 | 2.321 | 2.713 | 3.135 | 3.745 | 4.238 |
| 280 mm | 0.249 | 0.388 | 0.559 | 0.761 | 0.994 | 1.258 | 1.659 | 1.995 | 2.363 | 2.762 | 3.192 | 3.813 | 4.316 |
| 290 mm | 0.257 | 0.402 | 0.579 | 0.788 | 1.030 | 1.303 | 1.718 | 2.067 | 2.448 | 2.861 | 3.306 | 3.949 | 4.470 |
| 300 mm | 0.266 | 0.416 | 0.599 | 0.816 | 1.065 | 1.348 | 1.777 | 2.138 | 2.532 | 2.959 | 3.420 | 4.086 | 4.624 |
<
div class=”column mcb-column mcb-item-cv0p91qo1 one column_column”>
Weights For DIN 975 – Weight In Kgs. Per 1,000 Pcs. All Weights Are Approximations
| Size | Weight |
|---|---|
| M2 | 18.7 |
| M2.5 | 30.0 |
| M3 | 44.0 |
| M3.5 | 60.0 |
| M4 | 78.0 |
| M5 | 124 |
| M6 | 177 |
| M8 | 319 |
| M10 | 500 |
| M12 | 725 |
| M14 | 970 |
| M16 | 1330 |
| M18 | 1650 |
| M20 | 2080 |
| M22 | 2540 |
| M24 | 3000 |
| M27 | 3850 |
| M30 | 4750 |
| M33 | 5900 |
| M36 | 6900 |
| M39 | 8200 |
| M42 | 9400 |
| M45 | 11000 |
| M48 | 12400 |
